- What is Shaft Deflection?
Shaft deflection occurs when the pump shaft bends under hydraulic or mechanical load, typically caused by unbalanced forces from the impeller or wear rings. This deviation from the shaft’s natural axis—however slight—can introduce significant stress into the pump assembly.
- Why It’s a Big Deal in Mining
Mining applications often involve highly abrasive slurries, high pressures, and long-duty cycles. These harsh conditions increase radial loading on the shaft, making deflection more likely. The effect being:
- Premature Seal and Bearing Failure – Misalignment due to shaft deflection can rapidly wear out mechanical seals and overload bearings.
- Increased Vibration – Even minor deflection can amplify pump vibration, reducing equipment life and risking catastrophic failure.
- Reduced Efficiency – Excessive shaft movement can lead to misalignment within the hydraulic passage, lowering overall performance.
- How to Avoid Shaft Deflection in Mining Pumps
- Avoid Off-BEP Operation
Operating far to the left or right of the Best Efficiency Point (BEP) causes uneven forces, and is the most common cause of shaft deflection and mechanical seal failure.
- Select a Pump with a Stiff Shaft Design
Look for pumps engineered with larger-diameter shafts and minimal overhang between the bearing and impeller.
- Use Proper Impeller Sizing
Oversized or unbalanced impellers increase radial loads. Match the impeller diameter and trim carefully to your duty point.
- Maintain Proper Clearances
Worn or improperly set wear rings and impellers can create imbalances and contribute to side loading.
- Monitor and Maintain Bearings
Healthy, well-lubricated bearings help stabilize the shaft and limit movement under load.
- Use a pump monitoring system to track your operating point and vibration. Cornell’s Co-Pilot system can be outfitted with pressure sensors, vibration sensors, and a flow meter to ensure healthy operation of your pump.At Cornell Pump, our mining-duty series pumps such as SM, MP, SP, N, and MX are designed with shaft deflection in mind—using thick shafts, oversized bearings, and wear-resistant materials to handle abrasive duty cycles without compromising performance.
Keep your mine site running reliably—choose pump designs that stand up to the forces at work underground.
Learn more about Cornell Pump mining series here: https://www.cornellpump.com/markets/mining/
