Clear Liquid Pumps
Cornell’s clear liquid centrifugal pumps are commonly used in agricultural irrigation and are known for their superior efficiency. These pumps are designed to save energy costs, potentially saving thousands of dollars annually depending on usage. With a wide range of options available, Cornell offers clear liquid pumps that meet or exceed efficiency standards for centrifugal pumps.
W, Y, R, & H Series Pumps
Cornell's clear liquid centrifugal pumps are commonly used in agricultural irrigation and are known for their superior efficiency. Depending on usage, these pumps are designed to save energy costs, potentially saving thousands of dollars annually. With a wide range of options available, Cornell offers clear liquid pumps that meet or exceed efficiency standards for centrifugal pumps.
- Replaceable wear rings
- Double volute
- Various mounting configurations are available, including close-coupled, frame-mounted, and engine-mounted
- Robust Mount Frame with mounting surfaces
- Shower curtain shield on close-coupled models
- Oversized bearings
- High-efficiency, fully-machined impellers
- Efficiencies up to 89%
- Heavy walled castings
- External balance line
- Two-year warranty
| Model | Discharge | Suction | Solids Handling | Data Sheet |
| 1.25W | 1.25" | 1.5" | .25" | Data Sheet |
| 1WC | 1" | 1.5" | .25" | Data Sheet |
| 1.5WH | 1.5" | 2" | .28" | Data Sheet |
| 1.5YH | 1.5" | 2" | .25" | Data Sheet |
| 2WHA | 2" | 2.5" | .34" | Data Sheet |
| 2YH | 2" | 2.5" | .31" | Data Sheet |
| 2.5H-CC | 2.5" | 4" | .41" | Data Sheet |
| 2.5RB | 2.5 | 4 | .38" | Data Sheet |
| 4WH-F | 4" | 5" | 1.19" | Data Sheet |
| 6HH-F | 6" | 8" | 1.22" | Data Sheet |
| 2.5WB | 2.5" | 3" | .5" | Data Sheet |
| 2.5WH | 2.5" | 3" | .5" | Data Sheet |
| 2.5YH | 2.5" | 4" | .5" | Data Sheet |
| 2.5YM | 2.5" | 4" | .88" | Data Sheet |
| 3HA | 3" | 6" | .5" | Data Sheet |
| 3HC | 3" | 6" | .5" | Data Sheet |
| 3HC-CC | 3" | 6" | .5" | Data Sheet |
| 3HM | 3" | 5" | 1" | Data Sheet |
| 3RB-F | 3" | 5" | .5" | Data Sheet |
| 3RB-CC | 3" | 5" | .5" | Data Sheet |
| 3RC | 3" | 6" | .5" | Data Sheet |
| 3WHA-CC | 3" | 4" | .5" | Data Sheet |
| 3WHA-F | 3" | 4" | .5" | Data Sheet |
| 3WM | 3" | 4" | 1.2" | Data Sheet |
| 3YH | 3" | 4" | .5" | Data Sheet |
| 4HC | 4" | 8" | .62" | Data Sheet |
| 4HC-CC | 4" | 8" | .62" | Data Sheet |
| 4HH-CC | 4" | 6" | .62" | Data Sheet |
| 4HH-F | 4" | 6" | .62" | Data Sheet |
| 4HM | 3" | 5" | 1" | Data Sheet |
| 4RC | 4" | 6" | .84" | Data Sheet |
| 4WH | 4" | 5" | 1.19 | Data Sheet |
| 4YB | 4" | 6" | .75" | Data Sheet |
| 5H-CC | 5" | 8" | .97" | Data Sheet |
| 5H-F | 5" | 8" | .97" | Data Sheet |
| 5HH-CC | 5" | 8" | 1" | Data Sheet |
| 5HH-F | 5" | 8" | 1" | Data Sheet |
| 5RB-CC | 5" | 8" | 1" | Data Sheet |
| 5RB-F | 5" | 8" | 1" | Data Sheet |
| 5WBH-CC | 5" | 8" | .75" | Data Sheet |
| 5WBH-F | 5" | 8" | .75" | Data Sheet |
| 5WBQ | 5" | 8" | .75" | Data Sheet |
| 5YB | 5" | 8" | .62 | Data Sheet |
| 5YBH | 5" | 8" | .75" | Data Sheet |
| 5YBQ | 5" | 8" | .75" | Data Sheet |
| 6YB-F | 6" | 10" | .75" | Data Sheet |
| 6H-CC | 6" | 8" | 1.12" | Data Sheet |
| 6H-F | 6" | 8" | 1.12" | Data Sheet |
| 6HH-CC | 6" | 8" | 1.22" | Data Sheet |
| 6RB-F | 6" | 10" | 1.31" | Data Sheet |
| 6RB-CC | 6" | 10" | 1.31" | Data Sheet |
| 6YBQ-F | 6" | 10 | .75 | Data Sheet |
| 6YB-CC | 6" | 10" | .75" | Data Sheet |
| 6YBQ-CC | 6" | 10" | .75" | Data Sheet |
| 8H-CC | 8" | 10" | 1.25" | Data Sheet |
| 8H-F | 8" | 10" | 1.25 | Data Sheet |
| 10RB-F | 10" | 10" | 1.25" | Data Sheet |
| 10RB-CC | 10" | 10" | 1.25" | Data Sheet |
| 10YB-CC | 10" | 10" | 1.38" | Data Sheet |
| 10YB-F | 10" | 10" | 1.38" | Data Sheet |
| 10YBQ-CC | 10" | 10" | 1.38" | Data Sheet |
| 10YBQ-F | 10" | 10" | 1.38" | Data Sheet |
Edge End Gun Booster Pumps
Cornell's EDGE™ End Gun Booster pump for Center Irrigation Pivots is a retrofit that enhances pivot systems. With the reliable and renowned Cornell design, these competitively-priced pumps come in 3HP and 5HP models and can be shipped immediately.
- Discharge size: 2″ / Suction size: 2.5″
- 2B: 230 GPM and 130′ max head
- 2C: 130 GPM and 80′ max head
- Ideally suited for OEM center pivot booster applications
- Rotating assembly retrofits into Berkeley’s volute
- Performance meets or exceeds the competition
- 2B: Single mechanical seal
- Heavy-duty cast iron construction
- “Shower-Curtain” shield for motor moisture protection
- Motor built to Cornell specifications
- Off-the-shelf availability from multiple locations
- Two-year factory warranty
- IP55 wash down duty motor
| Model | Discharge | Suction | Solids Handling | Data Sheet |
| 2C | 2" | 2.5" | Data Sheet | |
| 2B | 2" | 2.5" | Data Sheet |
