Slurry Pumps

Cornell has introduced new Slurry pumps that cater to the dewatering pumping needs of abrasive applications in the mining and manure slurry industries. These slurry pumps are designed with Cornell’s patented Cycloseal® technology, which enables them to operate without the need for flush water.

SP-Series Pumps

Cornell's SP Series Slurry pump is designed for the mining process industry and features the patented Cycloseal® technology. The SP Series is a reliable solution for abrasive applications in the mill process. It is available in rubber and metal-lined configurations to handle different particle sizes and pH requirements.

Model Discharge Suction Solids Handling Data Sheet
2SP 2" 3" 1" Data Sheet
3SP 3" 4" 1.1" Data Sheet
4SP 4" 6" 1.7" Data Sheet
6SP 6" 8" 2.5" Data Sheet
8SP 8" 10" 3" Data Sheet
10SP 10" 12" 3.4" Data Sheet
12SP 12" 14" 3.5" Data Sheet

MP-Series Pumps

The MP-Series Pumps from Cornell Pump Company are built to withstand harsh conditions and handle coarse abrasives in slurry pumping applications such as coal, sand, gravel, manure, and mine dewatering. The pumps feature patented Cycloseal® technology and are designed with oversize shafts, thick volutes, and high-chrome white iron impellers for longer service life. With a unique pushed-out rectangular design, the MP series boasts the same quality and reliability associated with the Cornell pump brand.

Model Discharge Suction Solids Handling Data Sheet
2315MP 2" 3" .5" Data Sheet
3622MP 3" 6" .5" Data Sheet
4517MP 4" 5" 3" Data Sheet
4817MP 4" 8" 3" Data Sheet
6819MP 6" 8" 2" Data Sheet
6819MPC 6" 8" 3" Data Sheet
61017MP 6" 10" 3.38" Data Sheet
81022MP 8" 10" 4" Data Sheet
81022MPL 8" 10" 3.5" Data Sheet

SM-Series Pumps

The SM series consists of hard metal slurry pumps with a pressure rating of 600 PSI, suitable for high-head and multistage pumping applications. These pumps use high chrome white iron alloy for all wet-end components and feature an adjustable suction wear plate with the patented Cycloguard feature to reduce recirculation and increase wear life. The SM Pump has a unique appearance with an angular, muscular frame that signifies its high quality.

Model Discharge Suction Solids Handling Data Sheet
2309SM 2" 3" 1" Data Sheet
3412SM 3" 4" 1.1" Data Sheet
4616SM 4" 6" 2" Data Sheet
6820SM 6" 8" 2.5" Data Sheet
